Type
|
Digital,
single-lens reflex, AF/AE camera with built-in flash
|
|
Recording
medium
|
Type
I and II CF card
|
|
size
|
22.7
mm x 15.1 mm
|
|
Compatible
lenses
|
Canon
EF lenses
(35mm-equivalent focal length is equal to approx.1.6 times the
marked focal length.)
|
|
Lens
mount
|
Canon
EF mount
|
|
Sensor
|
|
Type
|
High-sensitivity,
high-resolution, single-plate CMOS sensor
|
|
Pixels
|
Effective
pixels: Approx. 6.30
megapixels (3088x2056)
|
|
Total
pixels
|
Approx.
6.50 megapixels (3152x2068)
|
|
Aspect
ratio
|
3:2
|
|
Color
filter system
|
RGB
primary color filter
|
|
Low-pass
filter
|
Located
in front of the image sensor, non-removable
|
|
Recording
System
|
|
Recording
format
|
JPEG
(except when Adobe RGB is set) supporting Design
rule for Camera File system and RAW
|
|
format
|
JPEG
and RAW (12-bit)
|
|
File
size
|
(1)
Large/Fine: Approx. 2.4 MB (3072x2048 pixels)
(2) Large/Normal: Approx. 1.2 MB (3072x2048 pixels)
(3) Medium/Fine: Approx. 1.3
MB (2048x1360 pixels)
(4) Medium/Normal: Approx. 0.7 MB (2048x1360 pixels)
(5) Small/Fine: Approx. 0.8 MB (1536x1024 pixels)
(6) Small/Normal: Approx. 0.4 MB (1536x1024 pixels)
(7) RAW (3072x2048 pixels)
RAW + Small/Normal: Approx. 6.0 MB
RAW + Small/Fine: Approx. 6.4 MB
RAW + Medium/Normal: Approx. 6.2 MB
RAW + Medium/Fine: Approx. 6.8 MB
RAW + Large/Normal: Approx. 6.7 MB
RAW + Large/Fine: Approx. 8.0 MB
* Exact file sizes depend on the subject and ISO speed.
|
|
File
numbering
|
Consecutive
numbering, auto reset
|
|
Color
space
|
sRGB,
Adobe RGB
Standard parameters plus up to three sets of custom processing
parameters (4 items with 5 settings each) can be set.
|
|
Processing
parameters
|
|
Interface
|
USB
(with dedicated cable)
|
|
White
Balance
|
|
Settings
|
Auto,
daylight, shade, cloudy, tungsten light, fluorescent light,
flash, manual, color temperature setting
|
|
Auto
white balance
|
Auto
white balance with the image sensor
|
|
Color
temperature
compensation
|
White
balance bracketing: +/-3 stops in whole-stop increments
|
|
Viewfinder
|
|
Type
|
Eye-level
pentaprism
|
|
Coverage
|
95%
vertically and horizontally with respect to the effective pixels
|
|
Magnification
|
0.88x
(-1 diopter with 50mm lens at infinity)
|
|
Eye
point
|
20
mm
|
|
Dioptric
adjustment range
|
-3.0
- +1.0 diopter
|
|
Focusing
screen
|
Fixed,
New Laser Matte screen
|
|
Mirror
|
Quick-return
half mirror
(Transmission:reflection ratio of 40:60, no mirror cut-off with
EF 600mm f/4 or shorter lens)
|
|
Viewfinder
information
|
AF
(AF points, focus confirmation light), exposure (shutter speed,
aperture value, manual exposure, AE lock, exposure compensation
amount, AEB level, partial metering area), flash (flash ready,
red-eye reduction lamp on, high-speed sync, FE lock, flash
exposure compensation amount), warnings (exposure warning,
improper FE lock warning, CF card full warning, CF card error
warning, no CF card warning, busy), maximum burst for continuous
shooting, shots remaining Depth-of-field preview: Enabled with
depth-of-field preview button
|
|
Autofocus
|
|
Type
|
TTL-CT-SIR
with a CMOS sensor
(TTL secondary image-registration, phase detection)
|
|
AF
points
|
7
|
|
AF
working range
|
EV
0.5-18 (at 20óæC, ISO 100)
|
|
Focusing
modes
|
One-Shot
AF, AI Servo AF, AI Focus AF, Manual focusing (MF)
|
|
AF
point selection
|
Automatic
selection, manual selection, home position
|
|
Active
AF point indicator
|
Superimposed
in viewfinder and indicated on LCD panel
|
|
AF-assist
beam
|
Stroboscopic
flash
|
|
Effective
range
|
Approx.
4.0m/13.1ft. at center, approx. 3.5m/11.5ft. off-center
|
|
Exposure
Control
|
|
Metering
system
|
TTL
full aperture metering with 35-zone SPC
(1) Evaluative metering (linkable to any AF point)
(2) Partial metering (approx. 9% of viewfinder at
center)
(3) Centerweighted average metering
|
|
Metering
range
|
EV
1-20 (at 20óæC with 50mm f/1.4 lens, ISO 100)
|
|
Exposure
control systems
|
Program
AE (Full Auto, Portrait, Landscape, Close-up, Sports, Night
Portrait, Flash Off, Program), shutter-priority AE,
aperture-priority AE, depth-of-field AE, manual exposure, ETTL
autoflash
|
|
ISO
speed
|
Basic
Zone modes: Automatic
|
|
Creative Zone modes
|
Equivalent
to ISO 100, 200, 400, 800, 1600, and ISO 3200 with ISO speed
extension.
|
|
Exposure
compensation
|
AEB:
+/-2 stops in 1/2- or 1/3-stop increments
|
|
Manual
|
+/-2
stops in 1/2- or 1/3-stop increments (can be combined with AEB)
|
|
AE
lock
|
Auto:
Applied when focus is achieved in the One Shot AF mode with
evaluative metering.
|
|
Manual
|
Applied
with AE lock button.
|
|
Shutter
|
|
Type
|
Electronically-controlled
focal-plane shutter
|
|
Shutter
speeds
|
1/4000
- 30 sec. (1/2- or 1/3-stop increments), bulb, X-sync at 1/200
sec.
|
|
Shutter
release
|
Soft-touch
electromagnetic release
|
|
Self-timer
|
10-sec.
delay
|
|
Remote
control
|
N3-type
remote control
|
|
Built-in
Flash
|
|
Type
|
Auto
pop-up E-TTL autoflash (retractable)
|
|
Guide
No
|
13
(ISO 100, meters), 43 (ISO 100, ft.)
|
|
Recycling
time
|
Approx.
3 sec.
|
|
Flash-ready
indicator
|
Flash-ready
icon lights in viewfinder
|
|
Flash
coverage
|
18mm
lens angle covered
|
|
Flash
metering system
|
E-TTL
autoflash (linked to all AF points)
|
|
Flash
exposure compensation
|
+/-2
stops in 1/2- and 1/3-stop increments
|
|
External
Speedlite
|
|
EOS-dedicated
Speedlites
|
E-TTL
autoflash set with EX-series Speedlites
|
|
PC
terminal
|
Provided
|
|
Drive
System
|
|
Drive
modes
|
Single
frame, continuous, self-timer
|
|
Continuous
shooting speed
|
Approx.
3 fps (at 1/250 sec. or faster speeds)
|
|
Max.
burst during
continuous shooting
|
9
shots
|
|
LCD
Monitor
|
|
Type
|
TFT
color liquid-crystal monitor
|
|
Screen
size
|
1.8
inches
|
|
Pixels
|
Approx.
118,000
|
|
coverage
|
Approx.
100% with respect to the effective pixels
|
|
Brightness control
|
5 levels
|
|
Playback
|
|
Image display format
|
Single image, single image (Info),
magnified view (approx. 1.5x - 10x in 15 steps, consecutive
magnified image viewing enabled), 9-image index, autoplay, image
rotation, and jump
|
|
Highlight alert
|
In the single image and single image (Info)
modes, any overexposed highlight areas with no image information
will blink
|
|
Image Protection and Erase
|
|
Protection
|
Single images can be protected or cancelled.
|
|
Erase
|
Single image or all images in the CF card
can be erased (except protected images).
|
|
Direct Printing from the Camera
|
|
Compatible printers
|
Canon card photo printers and BJ printers
for direct printing from the camera
|
|
Printable images
|
JPEG images
|
|
Settings
|
Print quantity, style (image, paper,
borders, date), and trimming
|
|
Menus
|
|
Menu
categories
|
Shooting
menu: Red
Playback menu: Blue
Set up menu: Yellow
|
|
LCD monitor language
|
12 languages provided (English, German,
French, Dutch, Danish, Finnish, Italian, Norwegian, Swedish,
Spanish, Simplified Chinese, and Japanese.)
|
|
Firmware update
|
Update possible by the user
|
|
Customize
Function
|
|
Custom
Functions
|
17
Custom Functions with 61 settings
|
|
Power
Source
|
|
Battery
|
One
Battery Pack BP-511/BP-512
*AC power can be supplied via the DC coupler.
|
|
Battery
life
|
|
Temperature
|
Shooting
Conditions
|
|
|
No
Flash
|
50%
Flash Use
|
|
At
20 °C / 68 °F
|
650
|
500
|
|
At
0°C / 32°F
|
500
|
400
|
*The
above figures apply when a
fully-charged Battery Pack BP-511/BP-512 is used.
|
|
Battery
check
|
Automatic
|
|
Power
saving
|
Provided.
Power turns off after 1, 2, 4, 8, 15, or 30 min.
|
|
Date/time
back-up battery
|
One
CR2025 lithium battery
|
|
Dimensions
and Weight
|
|
Dimensions
(W x H x D)
|
149.7
x 107.5 x 75.0 mm / 5.9 x 4.2 x 3.0 in
|
|
Weight
|
790
g / 27.9 oz (body only)
|
|
CANON EOS 10D SPORT
SETTING
|
Quality |
RAW |
|
Parameters |
Adobe RGB (don't change any of
the other settings) |
|
Auto-PowerOff |
30 Minutes, (It takes forever
to wake from Sleep) |
|
Auto-rotate |
On |
| LCD
Brightness |
DO NOT base your exposure on
the screen brightness. Please use a hand-held
meter or read your histogram. |
| File
numbering |
Continuous |
| Sensor
dust |
Turn the camera off when
changing lenses. If the sensor is charged, it
will pick up more dust. Also, clean the back of
your lenses before mounting. To clean your
sensor, use the "sensor cleaning" option in the
menu to lock up the mirror with an un-charged
sensor. Then use a blower bulb to gently clean.
NEVER use dust-off. |
| White
balance |
The 10D auto white balance is
not as good as the 1D or 1DS because there is no
external WB sensor. For the most accurate
balance, use custom WB by shooting a white card,
selecting that image in the "custom WB" menu
option, and then setting your white balance to "custom."
Your white card setting will ONLY be used when
you shoot on the "custom" setting. |
| 01 |
0 - The set button (in the
middle of the back dial) does nothing when
shooting |
| 02 |
1 - Can't release shutter if
no card in camera |
| 03 |
1 - Locks 1/200 sync in Av
mode |
| 04 |
1 - Set focus to back button (use
0 if you prefer to focus with the shutter) |
| 05 |
2 - Only fire AF assist light
when using external flash |
| 06 |
1 - 1/3 stop exposure
increments |
| 07 |
0 - Sets assist button default
focus piont to the center point |
| 08 |
5 - Largest JPEG used when
shooting RAW |
| 09 |
0 - Auto bracketing sequence |
| 10 |
0 - Focus point lights up in
viewfinder |
| 11 |
1 - When hitting menu button,
it defaults to the previous selected menu item.
We suggest leaving this on FORMAT so you can
reformat quickly every time you put a new card
in the camera |
| 12 |
0 - Setting this to 1 locks up
the mirror |
| 13 |
1 - Hitting the assist button
brings focus to the registered focus point (set
with CF#7) |
| 14 |
1 - Disable automatic
fill-flash reduction |
| 15 |
0 - 1st curtain flash sync |
| 16 |
0 - Disables safety shift in
Av or Tv mode |
| 17 |
0 - Sets black button on front
of long lenses to AF stop |
|
