SPECIFICATION |
| Type |
Digital
AF/AE SLR |
| Recording
medium |
Type
I and II CF card |
| Image
size |
35.8
x 23.8 mm (1.4 x 1 in) |
| Compatible
lenses |
Canon
EF lenses |
| Lens
mount |
Canon
EF mount |
| Image
Element |
| Type |
High-sensitivity,
high-resolution, large single-plate CMOS sensor |
| Pixels |
Effective
pixels: Approx. 11.1 megapixels
Total pixels: Approx. 11.4 megapixels |
| Aspect
ratio |
3:2 |
| Color
filter system |
RGB
primary color filter |
| Low-pass
filter |
Located
in front of the CMOS sensor, non-removable |
| Recording
System |
| Recording
format |
Design
rule for Camera File system (except Color Matrix 4) and RAW |
| Image
format |
JPEG,
RAW, (12 bit) |
| RAW+JPEG |
Simultaneous
recording Provided |
| File
size |
(1)
Large/Fine: approx. 4.1 MB (4064 x 2704 pixels)
(2) Large/Normal: approx. 1.7 MB (4064 x 2704 pixels)
(3) Small/Fine: approx. 1.4 MB (2032 x 1352 pixels)
(4) RAW: approx. 11.4 MB (4064 x 2704 pixels)
*Exact file sizes depend on the subject and ISO speed |
| Folders |
Folder
creation and selection is possible |
| File
numbering |
(1)
Consecutive numbering
(2) Auto reset
(3) Manual reset |
| Processing
parameters |
Standard
parameters plus up to three custom processing parameters can be
set |
| Interface |
IEEE
1394 (with dedicated cable) |
| White
Balance |
| Settings |
Auto,
daylight, shade, cloudy, tungsten light, fluorescent light,
flash, custom, color temperature setting, Personal white balance
(10 Settings) |
| Auto
white balance |
Hybrid
Auto white balance with the CMOS sensor and a dedicated external
sensor |
| Personal
white balance |
Up
to three custom white balance settings can be registered |
| Colour
temperature compensation |
White
Balance bracketing : +/-3 stops in full-stop increments |
| Color
Matrix |
| Type |
Two
types of color space, sRGB and Adobe RGB. Preferable type is
selectable out of four types of color tone in sRGB (Total 5
types) |
| Viewfinder |
| Type |
Glass
pentaprism |
| Coverage |
Approx.100
percent vertically and horizontally with respect to the
effective pixels |
| Magnification |
0.7x
(-1 diopter with 50mm lens at infinity) |
| Eyepoint |
20mm |
| Dioptric
adjustment |
-3.0
- +1.0 diopter |
| Focusing
screen |
Interchangeable
(9 types), Standard focusing screen: Ec-CIII |
| Mirror |
Quick-return
half mirror (Transmission:reflection ratio of 37:63, no mirror
cut-off with EF 1200mm f/5.6 or shorter lens) |
| Viewfinder
information |
All
information (AF points, focus confirmation light) ,Exposure
information (shutter speed, aperture, manual exposure, metering
range, ISO speed, exposure level, exposure warning) ,Flash
information (flash ready, FP flash, FE lock, flash exposure
level), JPEG format, number of remaining shots, CF card
information |
| Depth-of-field |
Enabled
with depth-of-field preview button |
| Eyepiece
shutter |
Built-in |
| Autofocus |
| Type |
TTL-AREA-SIR
with a CMOS sensor |
| AF
points |
45
AF points (Area AF) |
| AF
working range |
EV
0-18 (at ISO 100) |
| Focusing
modes |
One-Shot
AF
AI Servo AF
Manual focusing (MF) |
| AF
point selection |
Automatic
selection, manual selection, home position (switch to registered
AF point) |
| Selected
AF point display |
Superimposed
in viewfinder and indicated on top LCD panel |
| AF
assist beam |
AF-assist
beam is emitted by the dedicated Speedlite |
| Exposure
Control |
| Metering
modes available |
TTL
full aperture metering with 21-zone SPC
(1) Evaluative metering (linkable to any AF point)
(2) Partial metering (approx. 8.5% of viewfinder at center)
(3) Spot metering
- Center spot metering (approx. 2.4% of
viewfinder at center)
- AF point-linked spot metering (approx. 2.4%
of viewfinder)
- Multi-spot metering (Max. 8 spot metering
entries
(4) Centerweighted average metering |
| Metering
range |
EV
0-20 (at 20°C with 50mm f/1.4 lens, ISO 100) |
| Exposure
control systems |
Program
AE (shiftable), shutter-priority AE, aperture-priority AE,
depth-of-field AE, E-TTL autoflash, manual, flash metered manual |
| ISO
speed range |
Equivalent
to ISO 100-1250 (in 1/3-stop increments), ISO speed can be
expanded to ISO 50 |
| Exposure
compensation |
Auto
exposure bracketing (AEB): +/-3 stops in 1/3-stop increments.
Bracketing methods
(1) Shutter speed or aperture
(2) ISO speed :
Manual: +/-3 stops in 1/3-stop increments (can be combined with
AEB) |
| AE
lock |
Auto:
Operates in One-Shot AF mode with evaluative metering when focus
is achieved
Manual: By AE lock button in all metering modes |
| Shutter |
| Type |
Electoronically-controlled,
focal-plane shutter |
| Shutter
speed |
1/8000
to 30 sec. (1/3-stop increments), bulb, X-sync at 1/250 sec |
| Shutter
release |
Soft-touch
electromagnetic release |
| Self-timer |
10-sec.
or 2-sec. delay |
| Remote
control |
Remote
Control N3 type contact |
| Flash |
| EOS
dedicated Speedlite |
E-TTL
autoflash with EX series Speedlite |
| PC
terminal |
Provided |
| Drive
System |
| Drive
modes |
Single/Continuous |
| Continuous
shooting speed |
Approx.
3 fps |
| Max.
burst during continuous shooting |
10
shots
*The maximum shots per burst depends on the subject, shooting
mode, and ISO Speed |
| LCD
Monitor |
| Type |
TFT
color LCD monitor |
| Monitor
size |
2.0
inches |
| Pixels |
Approx.
120,000 |
| Coverage |
100%
with respect to the effective pixels |
| Brightness
control |
Adjustable
to one of five levels |
| Image
Playback |
| Image
display format |
(1)
Single image with information
(2) Single image
(3) 4-image index
(4) 9-image index
(5) Magnified view (P.Fn-30) |
| Highlight
alert |
In
display formats 1 and 2 above, any overexposed highlight areas
will blink in the image display |
| Image
Protection and Erase |
| Protection |
Erase
protection of one image, all images in a folder, or all images
in the CF card can be applied or canceled at one time |
| Erase |
One
image, all images in a folder, or all images in the CF card can
be erased (except protected images) at one time |
| Sound
Recording |
| Recording
method |
The
voice narration recorded with the built-in microphone is
attached to the image |
| File
format |
WAV |
| Recording
time |
Max.
30 sec. per recording |
| Menus |
| Menu
categories |
(1)
Recording menu
(2) Playback menu
(3) Setup menu
(4) Custom/Personal Functions menu |
| LCD
monitor language |
Japanese,
English, French, German, Spanish |
| Firmware
update |
Update
possible by the user |
| CUSTOMIZATION
MENUS |
| Custom
functions |
21
with 67 settings |
| Personal
functions |
26 |
| Power
Source |
| Battery |
One
Ni-MH Pack NP-E3
*AC power can be supplied via AC adapter and DC coupler |
| Number
of shots |
At
20°C/68F: Approx. 600
At 0°C/32F: Approx. 450
*The above figures apply when a fully-charged Ni-MH Pack NP-E3
is used |
| Battery
check |
Automatic |
| Power
saving |
Provided.
Power turns off after 1, 2, 4, 8, 15, or 30 min. |
| Back-up
battery |
One
CR2025 lithium battery |
| Dimensions
and Weight |
Dimensions
(W x H x D) |
156
x 157.6 x 79. 9 mm / 6.1 x 6.2 x 3.1 in. |
| Weight |
1265
g / 44.6 oz. (Body only) ,Battery: 335 g/ 11.8 oz.) |
| Working
Condictions |
| Working
temperature range |
0°C
- 45°C / 32°F-113°F |
| Working
humidity |
85%
or lower |
