Features

Sensor	• 22.3 x 14.9 mm CMOS sensor • RGB Color Filter Array • Built-in fixed low-pass filter (with self-cleaning unit) • 15.5 million total pixels • 15.1 million effective pixels • 3:2 aspect ratio
Image processor	DIGIC 4
A/D conversion	14 bit
Image sizes	• 4752 x 3168 • 3456 x 2304 • 2353 x 1568
File formats	• RAW (.CR2; 14-bit) • JPEG (EXIF 2.21) - Fine / Normal • RAW + JPEG (separate files) • sRAW1 (7.1 MP) • sRAW2 (3.8 MP)
Lenses	• Canon EF / EF-S lens mount • 1.6x field of view crop
Dust reduction	• "EOS Integrated Cleaning System" • Self-cleaning sensor unit (filter in front of sensor vibrates at high frequency at start-up and shutdown - can be disabled) • Dust Delete Data - Data from a test shot is used to 'map' dust spots and can be later removed using Canon DPP Software
Auto focus	• 9-point TTL CMOS sensor • All points cross-type for lenses of F5.6 or faster • Center point additionally sensitive with lenses of F2.8 or faster • AF working range: -0.5 - 18 EV (at 23°C, ISO 100)
Focus modes	• One shot AF • AI Servo AF • AI Focus AF • Manual focus
AF point selection	• Auto • Manual
Predictive AF	• Up to 8 m
AF assist	• Stroboscopic flash
AF microadjust	• +/- 20 steps • Adjust all lenses by same amount/individually adjust up to 20 lenses
Metering	• TTL 35 zone SPC • Metering range: EV 0.0 - 20 EV
Metering modes	• Evaluative 35 zone • Partial (9% at center) • Spot metering (approx. 3.8% at center) • Center-weighted average
AE lock	• Auto: One Shot AF with evaluative metering • Manual: AE lock button
Exposure compensation	• +/-2.0 EV • 0.3 or 0.5 EV increments
Exposure bracketing	• +/- 2.0 EV • 0.3 or 0.5 EV increments
Sensitivity	• Auto ISO (100-1600) • ISO 100 - 3200 • 0.3 or 1.0 EV increments • H1 (6400) and H2 (12800) expansion
Shutter	• Focal-plane shutter • 100,000 exposure durability • 30 - 1/8000 sec • 0.3 or 0.5 EV increments • Flash X-Sync: 1/250 sec • Bulb
Aperture values	• F1.0 - F91 • 0.3 or 0.5 EV increments • Actual aperture range depends on lens used
White balance	• Auto • Daylight • Shade • Cloudy • Tungsten • Fluorescent • Flash • Custom • Kelvin (2500 - 10000 K in 100 K steps)
WB bracketing	• +/-3 levels • 3 images • Blue / Amber or Magenta / Green bias
WB shift	• Blue (-9) To Amber (+9) • Magenta (-9) to Green (+9)
Picture style	• Standard • Portrait • Landscape • Neutral • Faithful • Monochrome • User def. 1 • User def. 2 • User def. 3
Custom image parameters	• Sharpness: 0 to 7 • Contrast: -4 to +4 • Saturation: -4 to +4 • Color tone: -4 to +4 • B&W filter: N, Ye, Or, R, G • B&W tone: N, S, B, P, G
Image processing	• Highlight tone priority • Auto lighting optimizer (4 settings) • Long exposure noise reduction • High ISO noise reduction (4 settings) • Auto correction of lens peripheral illumination (vignetting)
Color space	• sRGB • Adobe RGB
Viewfinder	• Eye-level pentaprism • 95% frame coverage • Magnification: 0.95x(-1 diopter with 50 mm lens at infinity) • Eyepoint: 22 mm • Interchangeable focusing screen Ef-A standard (2 other types optional) • Dioptric adjustment: -3.0 to +1.0 diopter
Focusing screens (optional)	• Ef-A (Standard Precision Matte - included) • Ef-D (Precision Matte with grid) • Ef-S (Super Precision Matte for easier manual focus)
Mirror	• Quick-return half mirror (transmission:reflection ratio 40:60) • Mirror lock-up (once or multiple exposures)
Viewfinder info	• AF points • Focus confirmation light • ISO sensitivity • Shutter speed • Aperture • Manual exposure • AE Lock • Exposure compensation amount • AEB level • Spot metering area • Flash ready • Red-eye reduction lamp on • High-speed sync • FE Lock • Flash compensation amount • ISO speed (while changing) • WB correction (while changing) • Highlight tone priority icon * • B&W mode icon • Warnings • Maximum burst for continuous shooting • Buffer space
LCD monitor	• 3.0 " TFT LCD • 920,000 pixels • 7 brightness levels • 160 ° viewing angle • Dual anti-reflection
LCD Live view	• Live TTL display of scene from CMOS image sensor • 100% frame coverage • 30 fps • Real-time evaluative metering using CMOS image sensor • Best view or exposure simulation • Silent mode • Grid optional (x2) • Magnify optional (5x or 10x at AF point) • Three AF modes - Live mode/Quick mode/Face Detection • Histogram • Remote live view using EOS Utility 2.0 (via USB or WiFi/Ethernet using WFT)
Record review	• Off • On (histogram via INFO button) • Display mode same as last used Play mode • 2 / 4 / 8 sec / Hold
Playback modes	1. Single image with exposure, file number, storage slot 2. As 1 but also image count and quality 3. Detailed exposure information, thumbnail and luminance histogram 4. Less detailed exposure info., thumbnail, luminance and RGB histograms
Playback features	• Optional blinking highlight alert • Optional AF point display • Magnified view (up to 10x) • 2x2 or 3x3 thumbnail index • Jump (by 1, 10, 100 images / by screen or date) • Delete / Protect
Flash	• Auto pop-up E-TTL II auto flash • FOV coverage up to 17 mm (27 mm equiv.) • Guide number approx 13 m / 43 ft (ISO 100) • Cycle time approx. 3 sec • Flash compensation +/-2.0 EV in 0.3 or 0.5 EV increments • X-Sync: 1/250 sec
External flash	• E-TTL II auto flash with EX-series Speedlites • In-camera flash configuration (currently only 580 EX II) • Wireless multi-flash support • PC Sync
Shooting modes	• Auto • Creative auto • Program AE (P) • Shutter priority AE (Tv) • Aperture priority AE (Av) • Manual (M) • Auto depth-of-field • Portrait • Landscape • Close-up • Sports • Night portrait • Flash off • Camera user settings 1 • Camera user settings 2
Drive modes	• Single • High-speed continuous: 6.3 fps • Low-speed continuous: 3 fps • Self-timer: 2 or 10 sec (3 sec with mirror lock-up)
Burst buffer	• Large/Fine JPEG: 90 frames (with UDMA card) • RAW: 16 frames
Orientation sensor	Yes
Auto rotation	• On (recorded and LCD display) • On (recorded only) • Off
Custom functions	25 custom functions with 74 settings in 4 groups
Menu languages	• English • German • French • Dutch • Danish • Portuguese • Finnish • Italian • Norwegian • Swedish • Spanish • Greek • Russian • Polish • Czech • Hungarian • Romanian • Ukrainian • Turkish • Arabic • Thai • Simplified Chinese • Traditional Chinese • Korean • Japanese
Firmware	User upgradable
Portrait grip	• Optional WFT-E3/E3A • Optional BP-E2N battery grip • Optional BP-E2 battery grip
Connectivity	• USB 2.0 Hi-Speed • Video out • HDMI connector • N3 type wired remote control • PC Sync flash terminal • Communication terminal on base for WFT-E3/E3A
Storage	• Compact Flash Type I or II (inc. FAT32) • Supports UDMA cards • Canon Original Data Security Kit supported ("Original Image Data") • No CF card supplied
Power	• Lithium-Ion BP-511A rechargeable battery (supplied & charger) • Supports BP-511 / BP-511A / BP-512 / BP-514 • CR2016 Lithium battery (date/time backup) • Optional AC adapter
Wireless connectivity (optional WFT-E3/E3A)	• Mounts on base of camera and also acts as vertical grip • Has its own BP-511A battery • Wireless 802.11b / 802.11g • Wireless security: WEP, TKIP/AES, WPA-PSK, WPA2-PSK • Wireless methods: Infrastructure or Ad Hoc • Wired ethernet (100 Base-TX) • Transfer: FTP, PTP (remote control by computer), HTTP (view / remote fire) • USB host capable: External hard drives, flash drives • USB comms: GPS devices (records coordinates and altitude in image header)
Dimensions	146 x 108 x 74 mm (5.7 x 4.2 x 2.9 in)
Weight	• No battery: 730 g (1.6 lb) • With battery: 822 g (1.8 lb)
