More Digital Canon Eos: 1D, 1D Mark II, 1D Mark IIn, 1Ds, 1Ds Mark II, 5D, 20D,10D, 350D


Type
Type Digital AF/AE SLR
Recording medium Type I or II CF card, SD memory card
Image size 28.7 x 19.1mm
Compatible lenses Canon EF lenses (except EF-S lens)
(35mm-equivalent focal length is equal to approx. 1.3 times the marked focal length. )
Lens mount Canon EF mount
Image Sensor
Type High-sensitivity, high-resolution, large single-plate CMOS sensor
Pixels: Effective pixels Approx. 8.20 megapixels
Total pixels Approx. 8.50 megapixels
Aspect ratio 3:2
Color filter system RGB primary color filter
Low-pass filter Located in front of the image sensor, non-removable
Recording System
Recording format DCF 2.0 (Exif 2.21): JPEG and RAW
Image format JPEG, RAW (12-bit)
RAW+JPEG simultaneous recording
Provided
File size (1) L (Large): Approx. 2.8 MB (3504 x 2336 pixels)
(2) M1 (Medium1): Approx. 2.2 MB (3104 x 2072 pixels)
(3) M1 (Medium2): Approx. 1.7 MB (2544 x 1696 pixels)
(4) S (Small): Approx. 1.0 MB (1728 x 1152 pixels)
(5) RAW: Approx. 8.3 MB (3504 x 2336 pixels)
* JPEG quality: 8
* Exact file sizes depend on the JPEG quality, subject, ISO speed, etc.
Folder setting Folder creation/selection enabled
File numbering (1) Consecutive numbering
(2) Auto reset
(3) Manual reset
Processing parameters Standard parameters plus up to three custom processing parameters can be set

Color matrix Five standard types plus two types that can be registered with color matrix
Backup image recording Enabled (Same image recordable on CF card and SD memory card)
Interface IEEE1394 for personal computers
USB for direct printing
Video output (NTSC/PAL)
White Balance
Settings Auto, daylight, shade, cloudy, tungsten light, fluorescent light, flash, custom, color temperature setting, custom white balance (Total 10 settings)
Auto white balance Auto white balance with the image sensor
Color temperature compensation
White balance bracketing: ±3 stops in full-stop increments
White balance correction: ±9 stops in full-stop increments
* Blue/amber bias or magenta/green bias possible
Viewfinder
Type Eye-level pentaprism
Coverage Approx. 100 percent vertically and horizontally with respect to the effective pixels
Magnification 0.72x (-1 diopter with 50mm lens at infinity)
Eye point 20 mm
Built-in dioptric adjustment -3.0 - +1.0 diopter
Focusing screen Interchangeable (9 types), Standard focusing screen: Ec-CIII
Mirror Quick-return half mirror (Transmission:reflection ratio of 37:63,
no mirror cut-off with EF 1200mm f/5.6 or shorter lens)
Viewfinder information AF information (AF points, focus confirmation light), exposure information (shutter speed, aperture, manual exposure, spot metering circle, ISO speed, exposure level, exposure warning), flash information (flash ready, FP flash, FE lock, flash exposure level), white balance correction, JPEG recording, number of remaining shots, memory card information
Depth-of-field preview Enabled with depth-of-field preview button
Eyepiece shutter Built-in
Autofocus
Type TTL-AREA-SIR with a CMOS sensor
AF points 45 AF points (Area AF)
AF working range EV 0-18 (at ISO 100 at 20°C/68°F)
Focusing modes One-Shot AF (ONE SHOT)
AI Servo AF (AI SERVO)
Manual focusing (MF)
AF point selection Automatic selection, manual selection, home position (switch to registered AF point)
Selected AF point display Superimposed in viewfinder and indicated on LCD panel
AF-assist beam Emitted by the dedicated Speedlite
Exposure Control
Metering modes 21-zone TTL full aperture metering
(1) Evaluative metering (linkable to any AF point)
(2) Partial metering (approx. 13.5% of viewfinder at center)
(3) Spot metering
• Center spot metering (approx. 3.8% of viewfinder at center)
• AF point-linked spot metering (approx. 3.8% of viewfinder)
• Multi-spot metering (Max. 8 spot metering entries)
(4) Centerweighted averaged metering
Metering range EV 0-20 (at 20°C/68°F with 50mm f/1.4 lens, ISO 100)
Exposure control systems Program AE (shiftable), shutter-priority AE, aperture priority AE, E-TTL II autoflash, manual, flash metered manual
ISO speed range Equivalent to ISO 100-1600 (in 1/3-stop increments), ISO speed can be expanded to ISO 50 and 3200
Exposure compensation AEB: ±3 stops in 1/3-stop increments.
Bracketing methods:
1. Shutter speed or aperture
2. ISO speed
Manual:
±3 stops in 1/3-stop increments (can be combined with AEB)
AE lock Auto: Applied in One-Shot AF mode with evaluative metering when focus is achieved.
Manual: By AE lock button in all metering modes.
Shutter
Type Electronically-controlled focal-plane shutter
Shutter speeds 1/8000 to 30 sec. (1/3-stop increments), bulb, X-sync at 1/250 sec.
Shutter release Soft-touch electromagnetic release
Self-timer 10-sec. or 2-sec. delay
Remote control Remote control with N3 type terminal
Flash
EOS-dedicated Speedlite E-TTL II autoflash with EX-series Speedlite
PC terminal Provided
Drive System
Drive modes Single, low-speed continuous, high-speed continuous, self-timer
Continuous shooting speed Low-speed continuous: Approx. 3 shots/sec. High-speed continuous: Approx. 8.5 shots/sec.
Max. burst JPEG: Approx. 40 shots (Large, JPEG 8)
RAW: Approx. 20 shots
LCD Monitor
Type TFT color liquid-crystal monitor
Monitor size 2.0 in.
Pixels Approx. 230,000
Coverage 100% with respect to the effective pixels
Brightness adjustment Five levels provided
Interface languages 12
Playback
Image display format Single image, single image (INFO.), 4-image index, 9-image index, magnified zoom (approx. 1.5x - 10x), rotated image
Highlight alert In he single image and single image (INFO.) formats, any overexposed highlight areas will blink in the image display.
Image Protection and Erase
Protection Erase protection of one image, all images in a folder, or all images in the memory card can be applied or canceled at one time.
Erase One image, all images in a folder, or all images in the memory card can
be erased (except protected images) at one time.
Sound Recording
Recording method The voice annotation recorded with the built-in microphone is attached to the image.
File format WAV
Recording time Max. 30 sec. per recording
Direct Printing
Compatible printers CP Direct, Bubble Jet Direct, and PictBridge-compatible printers
Printable images JPEG images
(Print ordering enabled with DPOF version 1.1)
Customization
Custom Functions 21 Custom Functions with 67 settings
Personal Functions 27
Camera settings saving/reading
Possible
Power Source
Battery One Ni-MH Pack NP-E3
* AC power can be supplied via the AC adapter and DC coupler.
Number of possible shots At 20°C/68°F: Approx. 1200
At 0°C/32°F: Approx. 800
* The above figures apply when a fully-charged Ni-MH Pack NP-E3 is used.
Battery check Automatic
Power saving Provided. Power turns off after 1, 2, 4, 8, 15, or 30 min.
Date/time back-up battery One CR2025 lithium battery
Dimensions and Weight
Dimensions 156 (W) x 157.6 (H) x 79.9 (D) mm / 6.1 x 6.2 x 3.1 in.
Weight 1220 g/43 oz. (Body only. battery: 335 g/11.8 oz.)
Working Conditions
Operating temperature range 0°C- 45°C / 32°F - 113°F
Operating humidity range 85% or less




CANON EOS 1D MARK II SPORT SETTING



Rear data window - always check the following:
White balance settings user preference, but the Auto setting (AWB) is excellent.
File Setting RAW+L
SD card inserted If you also have an SD card inserted, make sure you are shooting to card #1 (CF)
File number is over 9000 If your file number is over 9000, you should reset to 0000 by going into the file numbering option (tools1 tab) and hit M-Reset.


Camera Menu Screen

Custom WB Use to pick your white frame for custom white balance.
JPEG Quality Change the "L" setting to 7
Parameters standard
Color Matrix 4AdobeRGB (Color Saturation - Standard & Color Tone - 0)
Review off
Review Time doesn't matter with review off
Noise reduction off unless needed. If on, it kicks in at 1/2 second or slower
ISO Expansion off


Playback

Protect Images
Rotate (for direct printing only)
Erase all on card don't use, better to reformat instead
Print order (for direct printing only)
Highlight alert on
Display AF points on
Histogram display Bright


Tools1

Auto power off 30 min
File Numbering continuous
Backup off
Auto rotate on
Save camera settings save all of the settings onto a card
Loading camera settings use this after downloading SI's settings
Format reformat every card before shooting


Tools2

LCD Brightness the Mark II screen is brighter than the old Canons
Date/time Set to local time
Language English
Video System NTSC
Firmware keep current
Sensor cleaning only use a bulb blower. Send to Canon for cleaning if possible


Fourth Menu Screen: Custom Functions

00 1 - setting for the 1D default focus screen
01 1 - viewfinder displays information during exposure
02 1 - can't release shutter if no card in camera
04 1 - sets back button for focusing and shutter for auto exposure lock
05 2 - can set aperture even if no lens on body
06 0 - 1/3 stop increments
07 0 - after focus locks in one-shot mode, the focusing ring will not work
08 0 - remaining shots displayed on top LCD, file number on back LCD
09 0 - sets auto exposure bracketing order and cancels aeb if lens is changed or power turned off
10 0 - AF point illuminates in the viewfinder
11 0 - sets which buttons you want to use to change AF points
12 0 - setting this to 1 locks up the mirror
13 1 - limits selectable AF points to 11 and links spot metering to the active AF point
14 0 - Evaluative E-TTL II
15 0 - 1st curtain flash sync
16 0 - disables safety shift in Av or Tv mode
17 1 - focus area when using a single point for auto focus.
18 1 - switch to registered AF point with one button push
19 0 - controls the lens' AF stop button
20 0 - Standard auto focus tracing
21 0 - Give preference to focus over drive speed


Notes:

Screen The screen is substantially brighter than the EOS 1D - use the histogram or a light meter to evaluate exposure
Camera The camera will keep writing if you accidentally open the card door, but DO NOT remove the card until the red light goes off.
SD Card The SD card should be used in an emergency if you can't change CF cards fast enough. Do not use it for backup. Make sure you ship the SD card with your take.
SD Card The SD card will not be accessed automatically. You have to manually change your setting to use the card.
Switch Cards If you switch to the SD card, make sure you switch back to the CF. If will not go back automatically.
Exposure It's better to overexpose than underexpose.
